Huawei Data Communication,S220S-24P4J,S220S-24P4J,S220S-24P4J (24*10/100…
Remarks If the upper-level circuit breaker for a device is also connected to many other devices, a C32 or above circuit breaker needs to be used. If the upper-level circuit breaker for a device is…
Specifikacia Huawei Data Communication,S220S-24P4J,S220S-24P4J,S220S-24P4J (24*10/100…
Remarks If the upper-level circuit breaker for a device is also connected to many other devices, a C32 or above circuit breaker needs to be used. If the upper-level circuit breaker for a device is connected only to this device, a C25 or below circuit breaker can be used. Certification EMC certification Safety certification Manufacturing certification Chassis material Metal Static power consumption [W] 18.74 Dimensions without packaging (H x W x D) [mm(in.)] Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 442 mm x 220 mm (1.72 in. x 17.40 in. x 8.66 in.) Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 442 mm x 227 mm (1.72 in. x 17.40 in. x 8.94 in.) Dimensions with packaging (H x W x D) [mm(in.)] 90.0 mm x 550.0 mm x 360.0 mm (3.54 in. x 21.65 in. x 14.17 in.) Chassis height [U] 1 Installation type Rack mounting,Desk mounting,Wall mounting Weight without packaging [kg(lb)] 2.8 kg (6.17 lb) Weight with packaging [kg(lb)] 3.71 kg (8.18 lb) Typical power consumption [W] 33.32 Typical heat dissipation [BTU/hour] 113.68 Maximum power consumption [W] - Without PoE: 38.58 W - Full PoE load: 482.55 W (PoE: 400 W) Maximum heat dissipation [BTU/hour] - Without PoE: 131.63 - Full PoE load: 1646.51 MTBF [years] 48.77 MTTR [hours] 2 Availability > 0.99999 Noise at normal temperature (acoustic power) [dB(A)] 52.8 Noise at high temperature (acoustic power) [dB(A)] 58.6 Noise at normal temperature (acoustic pressure) [dB(A)] 40.1 Number of power slots 0 Number of fans modules 2 Maximum number of physical ports on the entire device 28 Maximum number of 2.5GE ports 4 Maximum number of GE ports 28 Maximum number of FE ports 28 Long-term operating temperature [°C(°F)] –5°C to +45°C (23°F to 113°F) at an altitude of 0 to 1800 m (0 to 5905.44 ft.) Restriction on the operating temperature variation rate [°C(°F)] When the altitude is 1800-5000 m (5906-16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.). Devices cannot start when the temperature is lower than 0°C (32°F). Storage temperature [°C(°F)] –40°C to +70°C (–40°F to +158°F) Long-term operating relative humidity [RH] 5% RH to 95% RH (non-condensing) Long-term operating altitude [m(ft.)] 0–5000 m (0–16404 ft.) Storage altitude [m(ft.)] 0-5000 m (0-16404 ft.) Power supply mode AC built-in Rated input voltage [V] - AC input: 100 V AC to 240 V AC, 50/60 Hz - High-voltage DC input: 240 V DC Input voltage range [V] - AC input: 90 V AC to 290 V AC; 45 Hz to 65 Hz - High-voltage DC input: 190 V DC to 290 V DC Maximum input current [A] 6 A Power supply surge protection [kV] Differential mode: ±6 kV; common mode: ±6 kV Ingress protection level (dustproof/waterproof) IP20 Types of fans Built-in Heat dissipation mode Air cooling for heat dissipation, intelligent fan speed adjustment Airflow direction Air intake from left and front, air exhaustion from right PoE Supported 100% power consumption [W] 33.92 Maximum PoE power consumption [W] 400 PoE+ power interfaces 24 Full load PoE power consumption 30W (802.3at) 13 Full load PoE power consumption 15.4W (802.3af) 24
