Ubiquiti UniFi switch Gen2 USW-16-POE 16x1000Mbps + 2x SFP PoE/PoE+ Fanless (42W)
Technical SpecificationsMechanical Dimensions 442 x 200 x 44 mm (17.4 x 7.9 x 1.7") Weight Without mounting brackets: 2.8 kg (6.2 lb) With mounting brackets: 2.9 kg (6.4 lb) Enclosure material SGCC…
Specifikacia Ubiquiti UniFi switch Gen2 USW-16-POE 16x1000Mbps + 2x SFP PoE/PoE+ Fanless (42W)
Technical SpecificationsMechanical Dimensions 442 x 200 x 44 mm (17.4 x 7.9 x 1.7") Weight Without mounting brackets: 2.8 kg (6.2 lb) With mounting brackets: 2.9 kg (6.4 lb) Enclosure material SGCC steel Hardware Management interface Ethernet In-Band Networking interface (16) GbE RJ45 ports (2) 1G SFP ports PoE interface (8) PoE/PoE+ (Pins 1, 2+; 3, 6-) Total non-blocking throughput 18 Gbps Switching capacity 36 Gbps Forwarding rate 26.78 Mpps Power method Universal input, 100—240V AC, 50/60 Hz Power supply AC/DC, internal, 60W Supported voltage range 100—240V AC Max. power consumption 18W (Excluding PoE output) Total available PoE 42W Max. PoE wattage per port by PSE PoE+: 32W Voltage range PoE mode PoE: 44—57V PoE+: 50—57V ESD/EMP protection Air: ± 16kV, contact: ± 12kV LCM display (1) 1.3" touchscreen Button Factory reset Shock and vibration ETSI300-019-1.4 Standard Ambient operating temperature -5 to 40° C (23 to 104° F) Ambient operating humidity 10 to 90% noncondensing Certifications CE, FCC, IC Switching Features Layer 2 features IGMP snooping STP / RSTP with priorities and port-level disable Port isolation Storm control Voice VLAN Port mirroring LACP port aggregation Multicast / broadcast rate limiting MAC address blocking Flow control 802.1X control Jumbo frames Proprietary loop protection DHCP snooping / guarding Egress rate limit LLDP-MED Port restricted by MAC Device isolation with ACLs LEDs System Status Ethernet PoE Speed/link/activity SFP Link/activity Application Requirements UniFi Network Version 7.2.94 and later
